Risco RisControl User Manual

111
SPECIFICATIONS
Operating Voltage
13.8V ±10%
Power consumption
170 mA, 5W max.
Display
8-inch IPS, Resolution 800x1280, Illumination 300 cd/m
2
Type of touch screen
Capacitive touch, 5-point touch control supported
System
Android 7.1.2
CPU
A83T Octa-core Cortex A7
Memory
1G DDR3M RAM, 8G EMMC Flash
Wi-Fi
802.11 b/g/n 2.4 GHz
Bluetooth
BT 4.0, 2.4 GHz
Z-Wave
EU – 868 MHz
IL – 916 MHz
US – 908 MHz
AU – 921 MHz
Output power: 4dBm Max
Output Power
20 dBm Max.
Operating Temperature
-10°C to 55°C (14°F to 131°F)
Speaker
1 speaker, 8 Ohm / 1W
Microphone
1xmic
Connections
USB – 1xtype C USB Jack
RS-485 – detachable terminal block
Tamper
1xTamper
Standard
EN50131-3, Grade 3 Environmental Class II,
PD 6662:2017
P/N
RP432KPTZAUA RisControl+ZWave for AU
RP432KPTZEUA RisControl+ZWave for EU
RP432KPTZILA RisControl+ZWave for IL
RP432KPTZUSA RisControl+ZWave for US

Risco RisControl Specifications

General

Brand	Risco
Model	RisControl
Category	Control Panel
Language	English
