5-45 100-Hour / Annual Inspection (continued)
B. Inspection
CABIN FORWARD FOOTWELLS
Tail Rotor Pedal Bearing Blocks:
Remove pedal bearing block covers as required. Examine accessible portion with
inspection light and mirror. Inspect condition. Check for looseness or play in
pedal bearings. Maximum allowable play is 0.080 inch axially and 0.030 inch
radially. Verify bearing block security.
Adjustable Tail Rotor Pedals:
Inspect condition. Verify no cracks in welds. Verify locking pins engage holes to
secure adjustable pedals. Verify proper operating clearance and smooth actuation.
Co-Pilot Removable Tail Rotor Pedals:
Inspect condition. Verify no cracks in welds. Verify locking pins engage holes to
secure removable pedals. Verify proper operating clearance and smooth actuation.
Cabin Heater Diffusers:
Inspect condition. Verify marking legibility. Verify no significant nicks, scratches
or dents, or cracks in welds. Verify security.
Fire Extinguisher and Mount:
Inspect condition. Inspect fire extinguisher per manufacturer’s instructions.
Verify no loss of charge or obstructions in extinguisher nozzle. Verify security.
Map Holders:
Inspect condition. Verify no defects, tears, or material deterioration. Remove
foreign objects and verify security.
License Holder:
Inspect condition. Verify no defects, cracks in plastic, or material deterioration.
Verify security.
Cabin Chin and Floor:
Inspect condition. Verify equipment security. Retrieve and discard trapped debris.
CONSOLE
Console Assembly:
Inspect condition. Verify no significant nicks, scratches or dents; verify no cracks,
corrosion, or loose rivets in lower console assembly. Verify hinge security.
HID Landing Lights:
Inspect condition. Verify proper installation and security of wiring and equipment.
Flight & Engine Instruments:
Inspect condition. Verify proper instrument markings per R66 POH Section 2.
Verify proper installation and security of wiring and equipment.
Page 5.14 Chapter 5 Inspections JUL 2020
