5-45 100-Hour / Annual Inspection (continued)
CONSOLE (continued)
Post Lights:
Inspect condition. Verify proper function and equipment security.
Fuel Cutoff Control and Guard:
Inspect condition. Verify cable and mounting bezel security. Verify proper adjustment
and smooth operation of knob. Verify guard is attached to console.
Radios and Radio Trays:
Inspect condition. Verify no cracks or corrosion. Verify proper installation and
security of wiring and equipment.
Pitot & Static Lines:
Inspect pitot and static lines for obstructions, cracking, chafing, pinching or kinking.
Verify integrity of pitot and static line connections. Verify line security.
Tail Rotor Pedal Bearing Block Supports:
Examine accessible portion with inspection light and mirror. Inspect both vertical sheet
metal supports inside lower console and verify no cracks. Pay particular attention to
area near NAS6603-13 bolts. Replace any cracked support prior to flight.
Tail Rotor Controls:
Examine accessible portion with inspection light and mirror. Inspect tail rotor control
components for obvious defects. Verify operating clearance.
Cabin Heater Hose:
Inspect condition. Verify no collapsed areas or chafing. Verify hose clamp and hose
security.
Copper Bus Bars:
Inspect condition. Verify no corrosion or bends in bus bar. Verify bus bar security and
isolation from surrounding structure.
Wiring:
Inspect condition. Verify no loose, chafed, or broken wires or terminals. Verify
neatness, proper routing and installation, and security.
Fasteners & Torque Stripes:
Inspect condition. Verify proper installation and security of fasteners. Renew
deteriorated torque stripes per Figure 5-1.
Close & Secure:
Verify foreign objects are removed. Verify equipment security and cleanliness of
interior. Close console and verify security.
APR 2017 Chapter 5 Inspections Page 5.15
