5-45 100-Hour / Annual Inspection (continued)
PILOT-SIDE CONSOLE (Optional equipment)
Pilot Avionics Support Weldment:
Inspect condition. Verify no significant nicks, scratches, or dents on console shell.
Verify no cracks in welds. Verify weldment mounting security.
CIRCUIT BREAKER PANEL
CAUTION
Ensure BATTERY switch is turned off while circuit breaker panel
is open.
Panel Cover:
Inspect condition. Verify no damage to nutplates and rails in panel interior. Verify
marking legibility.
Fuses and Fuse Holders:
Inspect condition. Verify security and no corrosion. Verify correct fuse installation.
Circuit Breakers:
Inspect condition. Check airworthiness directive applicability. Verify proper
installation and security.
Copper Bus Bars:
Inspect condition. Verify no corrosion or bends in bus bars. Verify bus bar security
and isolation from surrounding structure.
Wiring:
Inspect condition. Verify no loose, chafed, or broken wires or terminals. Verify
neatness, proper routing and installation, and security.
Fasteners & Torque Stripes:
Inspect condition. Verify proper installation and security of fasteners. Renew
deteriorated torque stripes per Figure 5-1.
Close & Secure:
Verify foreign objects are removed. Verify equipment security. Verify cleanliness of
interior and of access cover. Close cover and verify security.
UNDER LEFT FRONT SEAT
Lithium-Ion Battery Circuit Back-Up Batteries (required with optional Lithium-ion main
battery):
Inspect condition. Verify presence and proper orientation of (2) 9V back-up batteries.
Verify security of battery trays and G468-1 mount assembly. Verify legibility of
silkscreen lettering on mount. Inspect wiring for obvious damage.
Page 5.16 Chapter 5 Inspections APR 2017
