12-13 Chip Detector and Sight Gage (continued)
C. Installation
1. Refer to Figure 12-1. Verify cleanliness and clarity of sight gage. As required,
remove sight gage per Part A and clean with approved solvent per Section 20-70.
Install sight gage and special torque per Section 20-33.
2. Verify cleanliness of chip detector and housing. As required, remove and clean
chip detector and housing per Parts A and B. Install housing and special torque per
Section 20-33. Install chip detector.
3. Turn BATTERY switch ON. Verify MR CHIP warning segment illuminates when test
button is depressed. Turn BATTERY switch OFF.
SEP 2012 R66 Maintenance Manual Chapter 12 Servicing Page 12.5
