22-50 Cyclic Grip Assembly
Refer to R66 Illustrated Parts Catalog (IPC) Figures 22-1 & 67-11.
A. Grip Angle Adjustment
1. Loosen cap screws securing pilot's cyclic grip, block assembly, and bar to grip
weldment.
2. Rotate grip about weldment to desired angle. Special torque cap screws to 40 in.-lb.
B. Removal and Installation
Refer to § 67-12 for cyclic grip assembly removal and installation procedures.
To access grip switches:
1. Remove MS24693-S1 screws securing C214-27 plate to D379-1 grip. Remove switch
nuts and lockwashers to free switches from plate.
2. Install switch lockwashers (new) and nuts and tighten switches to plate; verify switch
security. Install screws securing plate to grip.
3. Turn battery switch on and perform ground checks as appropriate per § 22-61.
C. Schematic
Refer to MM Figure 98-1 for F024 electrical system schematic.
