25 OCT 2010 R66 Maintenance Manual Chapter 25 Furnishings Page 25.9
25-52 License Holder Replacement
Refer to R66 Illustrated Parts Catalog (IPC) Figure 25-11.
A. Removal
1. Remove aircraft documents from license holder.
2. Drill out rivets securing license holder to cabin under left side windshield frame and
remove license holder. Deburr holes and clean up debris.
B. Installation
1. Cleco license holder to cabin holes under left side windshield frame. Remove clecos
and install rivets. Verify security.
2. Insert aircraft documents into holder and tuck upper flap into frame.
25-53 Map Pocket Replacement
Refer to R66 Illustrated Parts Catalog (IPC) Figure 25-11.
A. Removal
1. Drill out rivets securing map pocket to front wall of forward seat box. Remove
pocket, washers, and retaining strips. Deburr holes and clean up debris.
B. Installation
1. Fold (long) outboard pocket edge around (long) A913-1 strip, align holes, and align
holes with front of forward seat box. Cleco in place.
2. Pull material taut, fold (short) inboard pocket edge around (short) A913-2 strip, align
holes, and align holes with front of forward seat box. Cleco in place. Trim excess
material.
3. Remove clecos and install washers and rivets.
