MAY 2015 Chapter 33 Lights Page 33.3
33-13 Landing Lights
A. Removal
1. Turn battery switch off. Pull out LAND LT circuit breaker (7½ amp) at panel.
2. Remove screws securing C526-1 retainer to chin and remove retainer.
3. Disconnect landing light cable from lamp and remove lamp.
B. Installation
1. Turn battery switch off. Pull out LAND LT circuit breaker (7½ amp) at panel.
NOTE
B557-1 (spot) landing light is installed in LH location and B557-
2 (flood) taxi light is installed in RH location.
2. Connect landing light cable to landing light.
3. Install screws securing C526-1 retainer to chin.
4. Push in LAND LT circuit breaker (7½ amp) at panel. Turn battery switch and
landing light switch on (cyclic center post) and verify function. Turn battery switch
and landing light switch off.
33-20 Interior Lights
33-21 Panel Light
A. LED Assembly Replacement
1. Turn battery switch off. Pull out LTS circuit breaker (5 amp) at panel.
2. Remove hardware securing G196 light assembly to windshield stiffener. Remove
two cap screws securing cover and LED assembly to housing. Disconnect LED
assembly wires from airframe harness and remove LED assembly.
3. Connect F090-2289 (white) airframe harness wire to new LED assembly red wire,
and F090-2290 airframe harness wire to LED assembly black wire. Install cover
(chamfer facing away from housing) and install two cap screws. Install hardware
securing G196 light assembly to windshield stiffener. Verify security.
4. Push in LTS circuit breaker (5 amp) at panel. Turn battery switch and LTS switch
on and verify function. Verify dimming knob adjusts brightness. Turn battery
switch and LTS switch off.
