25-40 Insulation (Foam and Headliner)
Refer to R66 Illustrated Parts Catalog (IPC) Figure 25-17.
A. Removal
NOTE
Use caution not to damage surface underneath insulation when
removing insulation with tools.
NOTE
Insulation is installed using adhesive, except under seat
assemblies. Order new insulation as required; reuse of removed
insulation is not recommended.
1. Peel off insulation by hand.
2. Using plastic wedge or putty knife, carefully remove residual insulation and old
adhesive.
3. Wipe bonding surface with clean cloth, wet with acetone.
B. Installation
1. Verify proper insulation fit. Trim as required.
2. Apply B270-8 adhesive to bonding surface and insulation backing. Press insulation to
surface, smooth wrinkles, and remove excess adhesive prior to curing.
25-50 General Maintenance
25-51 Pilot's Operating Handbook (POH) Strap Replacement
Refer to R66 Illustrated Parts Catalog (IPC) Figure 25-19.
A. Removal
1. Remove POH.
2. Drill out rivets securing POH retaining strap to cabin right side and remove strap.
Deburr holes and clean up debris.
B. Installation
1. Cleco POH retaining strap to cabin right side holes. Remove clecos and install rivets.
Verify security.
2. Install POH.
Page 25.8 Chapter 25 Furnishings R66 Maintenance Manual SEP 2012
