Page 33.2 Chapter 33 Lights MAY 2015
33-11 Strobe Light(s) (continued)
B. Installation
1. Turn battery switch off. Pull out STROBE circuit breaker (5 amp, or 7½ amp if
forward strobe is installed) at panel.
2. Install hardware securing A708 strobe light assembly's ground wire to tailcone
mount, if ground is installed at mount. Connect light assembly's harness to airframe
harness at connectors.
3. Install hardware securing light assembly to tailcone mount (white forward strobe:
two missing columns of LEDs facing forward). Verify security.
4. Install hardware securing light assembly's gasket, lens, and retainer to light
assembly. Verify security.
5. Push in STROBE circuit breaker (5 amp, or 7½ amp if forward strobe is installed)
at panel. Turn battery switch and strobe switch(es) on and verify function. Turn
battery switch off.
33-12 Navigation Lights
A. Removal
1. Turn battery switch off. Pull out LTS circuit breaker (5 amp) at panel.
2. a. Position Lights: Remove screw securing retainer, lens, and gasket to light
assembly. Remove hardware securing light assembly, gasket, and ground wire
to chin. Cut and discard ty-rap securing excess wire to light assembly, pull out
light assembly, and disconnect light assembly harness from airframe harness at
connector.
b. Tail Light: Remove screws securing retainer, lens, gasket, and light assembly to
stabilizer mount. Pull out light assembly and disconnect light assembly harness
from airframe harness at connector.
B. Installation
1. Turn battery switch off. Pull out LTS circuit breaker (5 amp) at panel.
2. a. Position Lights: Connect light assembly harness to airframe harness at connector.
Install hardware securing light assembly, gasket, and ground wire to chin. Verify
security. Install ty-rap securing excess wire to light assembly. Cinch ty-rap
until snug without over-tightening, and trim tip flush with head. Install screw
securing retainer, lens, and gasket to light assembly. Verify security.
b. Tail Light: Connect light assembly harness to airframe harness at connector.
Install screws securing retainer, lens, gasket, and light assembly to stabilizer
mount. Verify security.
3. Push in LTS circuit breaker (5 amp) at panel. Turn battery switch and LTS switch
on and verify function. Turn battery switch and LTS switch off.
