97-20 Radar Altimeter Installation
Refer to R66 Illustrated Parts Catalog (IPC) Figures 97-15, 95-17, and 95-19.
A. Description
The FreeFlight RA-4500 radar altimeter has ARINC 429 output for communication with
electronic displays such as the G500H EFIS system. Radar altitude data can be displayed
on the PFD portion of the Garmin GDU 620 display.
B. Schematic
Refer to MM Figure 98-13 for Radar Altimeter Installation electrical schematic.
C. Removal
RAD-40 Indicator
1. Turn battery & avionics switches off and pull out RADAR ALT (2 amp) circuit breaker
at panel.
2. Remove perimeter screws securing instrument face to upper console and carefully pull
face aft, or remove Garmin GDU 620 Display per § 95-70.
3. a. For Above-Console Installation: Remove hardware securing B560 enclosure
assembly to instrument console and remove hardware securing B560 faceplate to
RAD-40 Indicator.
b. For In-Console Installation: Supporting RAD-40 indicator, remove hardware securing
B421-1 visor assembly, A590-4 cover plate, and indicator to instrument face.
4. Disconnect console harness from indicator and carefully remove indicator.
ATG-410 Tone Generator
1. Turn battery & avionics switches off and pull out RADAR ALT (2 amp) circuit breaker
at panel. Open instrument console or remove Garmin GDU 620 Display per § 95-70.
2. Supporting ATG-410 tone generator, remove screws securing tone generator to keel
panel. Carefully remove tone generator and disconnect console harness.
RA-4000/RA-4500 Radar Altimeter
1. Turn battery & avionics switches off and pull out RADAR ALT (2 amp) circuit breaker
at panel. Hinge front left seat forward.
2. Disconnect airframe and antenna harnesses from RA-4000/RA-4500 radar altimeter.
3. Supporting radar altimeter, remove screws securing radar altimeter to F542-2 support.
Carefully remove radar altimeter from under left seat.
MAY 2015 Chapter 97 Avionics Page 97.9
