99-20 Illustrations and Tasks
Item Part No. Name and Reference Section
1. MT054-1 Main Rotor Gearbox Drain Assembly - Quick Disconnect
REFER TO SECTION 12-11 MAIN ROTOR GEARBOX SERVICING
2. MT122-6 Micrometer Assembly - Main Rotor Hub, Bolt Stretch
REFER TO SECTION 62-10 MAIN ROTOR BLADES
3. MT146-4 Blocks - Swashplate Rigging (set of 2)
REFER TO SECTION 18-30 MAIN ROTOR FLIGHT CONTROL RIGGING
4. MT147-1 Bleed Tool - Main Rotor Blade Spindle
REFER TO SECTION 12-51 MAIN ROTOR BLADE SPINDLE SERVICING
5. MT179-4 Balancing Bar - Tail Rotor Assembly Static Balance
REFER TO SECTION 64-11 TAIL ROTOR ASSEMBLY STATIC BALANCE
6. MT260-6 Tail Rotor Drive Shaft Runout Attachments Kit
REFER TO SECTION 65-21 TAIL ROTOR DRIVE SHAFT RUNOUT
7. MT329-6 Plug - Main Rotor Hub Bearing Installation
REFER TO SECTION 62-21 MAIN ROTOR HUB BEARING REPLACEMENT
8. MT352-1 Main Rotor Blade Trim Tab Gage
REFER TO SECTION 18-13 MAIN ROTOR BLADE TRACK ADJUSTMENT
9. MT354-4 Teeter Moment Tool
REFER TO SECTION 62-32 ADJUSTING HINGE FRICTION
10. MT357-2 0.375-inch diameter Reamer
VARIOUS; REAM BORE AFTER INSTALLATION OF A139-1 BEARING TO 0.376/0.375-INCH DIA
11. MT357-3 0.156-inch diameter Steel Drill
REFER TO SECTION 62-33 DRILLING NUTS AND BOLTS
12. MT357-4 Hex Driver (Snap-On Part No. FABL8)
REFER TO SECTION 65-40 TAIL ROTOR GEARBOX
13. MT357-5 Torque Adapter (Snap-On Part No. FRDH101)
REFER TO SECTION 65-40 TAIL ROTOR GEARBOX
14. MT359-1 Spring Scale (0-30 lb)
REFER TO SECTION 62-32 ADJUSTING HINGE FRICTION AND SECTION 67-22 COLLECTIVE FRICTION
15. MT384-1 Hydraulic Test Pump (U.S / Canada / Mexico - 110-volt)
REFER TO SECTION 12-34 HYDRAULIC SYSTEM BLEEDING
16. MT384-2 Hydraulic Test Pump (Outside North America - 220-volt)
REFER TO SECTION 12-34 HYDRAULIC SYSTEM BLEEDING
SEP 2012 R66 Maintenance Manual Chapter 99 Special Tools Page 99.3
