4-22 Parts with a Recommended Replacement Time (continued)
Part Number Description Reference
C522-11 Control Cable
MM § 76-21 & IPC Figure 76-5
C947-3 Plate Assembly
MM § 65-10 & IPC Figure 65-1
D082-1 Tube Assembly
MM § 53-53 & IPC Figure 53-21
D224 Tail Rotor Drive Shaft Assembly
MM § 65-20 & IPC Figure 65-3
D918-1 Elastic Cord
MM § 67-10 & IPC Figures 67-1 & 67-5
D918-2 Elastic Cord
MM § 67-10 & IPC Figures 67-1 & 67-5
D918-3 Elastic Cord
MM § 67-10 & IPC Figures 67-1 & 67-5
D930-2 Safety Spring
MM § 76-10 & IPC Figure 76-1
F170-2 Fitting
MM § 71-30 & IPC Figure 71-13
F173-1 Strut
MM § 71-30 & IPC Figure 71-13
F579-1 Seal
MM § 71-23 & IPC Figure 71-11
F642-1, -6 Engine Shaft Weldment
MM § 63-10 & IPC Figure 63-1
F651-2 Element
MM § 12-12 & IPC Figure 63-13
F651-3 Seal Kit
MM § 12-12 & IPC Figure 63-13
F771-1 Filter
MM § 71-21 & IPC Figure 71-9
G727-1 Tube
MM § 71-30 & IPC Figure 71-13
G732-3 Cap
MM § 63-12 & IPC Figure 63-1
MS21919WCH12 Clamp
MM § 71-30 & IPC Figure 71-13
MS24665-423 Cotter Pin
MM § 62-10 & IPC Figure 62-3
MS28778-4 Packing
MM § 79-30 & IPC Figure 79-7
MS28778-8 Packing
MM § 79-30 & IPC Figure 79-7
MS29512-10 Packing
MM § 28-11 & IPC Figure 28-1
NAS557-32A Grommet
MM § 63-12 & IPC Figure 63-1
NAS617-12 Packing
MM § 71-30 & IPC Figure 71-13
NAS634-105 Bolt
MM § 62-10 & IPC Figure 62-3
NAS6604-67 Bolt
MM § 63-12 & IPC Figure 63-1
4-23 Airframe and Engine Accessory Limits
Refer to accessory manufacturer’s instructions for continued airworthiness for accessory
limits. Remove accessories per R66 Maintenance Manual or RR300 Operation and
Maintenance Manual (OMM) as required.
4-24 Engine Limits
Refer to RR300 Operation and Maintenance Manual (OMM) for engine limits. Prepare
engine for Rolls-Royce maintenance facility per § 71-11 as required.
4-30 Type Certificate Data Sheet (TCDS)
The Robinson R66 Type Certficate Data Sheet (TCDS) reprinted on the following pages is
subject to revision.
Visit the FAA Aircraft Certification Regulatory and Guidance Library online databases for
TCDS revision status at: http://rgl.faa.gov.
Page 4.4 Chapter 4 Airworthiness Limitations MAY 2015
