CHAPTER 25
FURNISHINGS
25-00 Description
The seats are not adjustable but the pilot-side pedals are adjustable. Each helicopter is supplied
with a cushion which can be placed behind the pilot to position him forward. This allows
shorter pilots to reach the pedals, the cyclic stick in its most forward position, and the controls
on the center console.
Each seat is equipped with a combined seat belt and inertia reel shoulder strap. The inertia reel
is normally free but will lock if there is sudden movement as would occur in an accident.
Five-point harnesses are optional for the front seats. The ve-point harness is equipped with
a webbing stop located above the inertia reel. The stop limits shoulder strap retraction and
should be adjusted so the straps are comfortable without excessive slack.
The main baggage compartment is located between the cabin and the engine compartment. It
is accessed via a large door on the aircraft right side. The cowl door annunciator illuminates
to warn the pilot when the door is not latched. A light illuminates the compartment when
the battery switch is ON. Tie down anchors are provided for securing items in the baggage
compartment. Observe placarded weight limits. Placard locations and illustrations are given
in Chapter 11.
Additional compartments are located under each seat except the center rear seat. Seat cushions
hinge forward for access to these compartments. Do not load these compartments above
the maximum ll lines. The lines indicate required crush space for the seats in an accident.
Baggage compartment dimensions are given in Chapter 6.
WARNING
Never repair or modify seat assemblies, including seat assembly
fabric, seat pans, or hook and loop tape (Velcro) securing fabric
to seat pans. Seat assembly energy-absorption design is critical
to occupant safety. To preserve crashworthiness, maintenance
is limited to seat assembly replacement.
SEP 2012 R66 Maintenance Manual Chapter 25 Furnishings Page 25.1
