53-31 Lower Frames (continued)
B. Installation
1. Refer to Figure 53-2.
a. F046-1 (LH) only: Install hardware securing shackle and frame to F574-8 block
(threaded). Special torque bolt per Section 20-33, and torque stripe per Figure
5-1. Install hardware securing frame to F574-5 block (insert bolt thru G246-1
brace, inside baggage compartment). Standard torque bolt per Section 20-32,
and torque stripe per Figure 5-1.
b. F046-2 (RH) only: Install hardware, and G914-5 tab, securing frame to F574-
1 support assembly (access bolts from inside baggage compartment). Remove
finish from surface under braided wire terminal. Standard torque bolts per Section
20-32, and torque stripe per Figure 5-1.
2. Install hardware securing F046 lower frame to F574-10 block assembly (threaded).
Install hardware securing F020-1 frame weldment, firewall, and F046 lower frame.
Standard torque bolts per Section 20-32, and torque stripe per Figure 5-1.
3. Verify rod end engagement in F174-1 support weldment is approximately 0.93
inch from tube end to rod end centerline on each side (nominal). Adjust rod ends
as required per Section 5-33, and Figures 5-1 & 5-2. Install hardware securing
weldment to lower frames, standard torque bolts per Section 20-32, and torque
stripe per Figure 5-1. Remove tailcone support.
4. Seal around frame weldment(s) at firewalls using B270-1 sealant.
5. Connect F049-03 harness assembly wires at plastic connectors, install hardware
securing clamps to firewall, and install ty-raps as required. Cinch ty-raps until snug
without over-tightening, and trim tips flush with heads.
6. a. F046-1 (LH) only: Install hardware securing power turbine governor control cable
clamps, F723-3 line assembly clamp, and firewall clamp to F046-1 lower frame.
Standard torque hardware per Section 20-32, and torque stripe per Figure 5-1.
b. F046-2 (RH) only: Install hardware securing battery cable harness clamp,
external power block, and stiffener clamp to F046-2 lower frame. Standard
torque hardware per Section 20-32, and torque stripe per Figure 5-1.
7. Install engine per Section 71-10.
25 OCT 2010 R66 Maintenance Manual Chapter 53 Fuselage Page 53.7
