FIGURE 62-17 BLADE TIP REPAIR LIMITS
Page 62.24 Chapter 62 Main Rotor R66 Maintenance Manual 25 OCT 2010
FIGURE 62-18 TIP CAP, SPAR, AND TRAILING EDGES - VOID AND DEBOND LIMITS
