Page 62.26 Chapter 62 Main Rotor R66 Maintenance Manual 25 OCT 2010
FIGURE 62-20 HONEYCOMB - VOID AND DEBOND LIMITS
FIGURE 62-19 DOUBLERS - VOID AND DEBOND LIMITS
