Page 5.14 Chapter 5 Inspection Schedule R66 Maintenance Manual SEP 2012
5-45 100-Hour / Annual Maintenance and Inspection [2 of 25 Pages]
CABIN FORWARD FOOTWELLS (continued)
Adjustable Tail Rotor Pedals:
Inspect condition. Verify no cracks in welds. Verify locking pins engage holes to
secure adjustable pedals. Verify proper operating clearance and smooth actuation.
Co-Pilot Removable Tail Rotor Pedals:
Inspect condition. Verify no cracks in welds. Verify locking pins engage holes to
secure removable pedals. Verify proper operating clearance and smooth actuation.
Cabin Heater Diffusers:
Inspect condition. Verify marking legibility. Verify no significant nicks, scratches or
dents, or cracks in welds. Verify security.
Fire Extinguisher and Mount:
Inspect condition. Inspect fire extinguisher per manufacturer’s instructions. Verify no
loss of charge or obstructions in extinguisher nozzle. Verify security.
Map Holders:
Inspect condition. Verify no defects, tears, or material deterioration. Remove foreign
objects and verify security.
License Holder:
Inspect condition. Verify no defects, cracks in plastic, or material deterioration. Verify
security.
Cabin Chin and Floor:
Inspect condition. Verify equipment security. Retrieve and discard trapped debris.
CONSOLE
Console Assembly:
Inspect condition. Verify no significant nicks, scratches or dents; verify no cracks,
corrosion, or loose rivets in lower console assembly. Verify hinge security.
HID Landing Lights:
Inspect condition. Verify proper installation and security of wiring and equipment.
Flight & Engine Instruments:
Inspect condition. Verify proper instrument markings per R66 POH Section 2. Verify
proper installation and security of wiring and equipment.
Post Lights:
Inspect condition. Verify proper function and equipment security.
Fuel Cutoff Control and Guard:
Inspect condition. Verify cable and mounting bezel security. Verify proper adjustment
and smooth operation of knob. Verify guard is attached to console.
Radios and Radio Trays:
Inspect condition. Verify no cracks or corrosion. Verify proper installation and security
of wiring and equipment.
Pitot & Static Lines:
Inspect pitot and static lines for obstructions, cracking, chafing, pinching or kinking.
Verify integrity of pitot and static line connections. Verify line security.
