Synchronisation of the rotary ring
The machine does not operate and does not block the film in the clamp if the rotary ring is not synchronised.
No matter what the position of the rotary ring is, when the START pedal is pressed, the machine will synchronise the
rotary ring instead of starting the operations.
Then, processing can be started.
Spool replacement
1. Display the main page.
2. Touch the key (A) to access the manual movements (see 6.3. “Description of control panel” - “Description of
control panel manual controls”)
3. Touch the “slewing ring” (B) key to enable it and then the “spool” key (C).
The spool carriage unit automatically moves in front of the door (D).
4. Open the door (D) to access the spool.
