AX10 Palletizing Solution
3.1. Scope of Delivery
l
1 x AX10 Palletizing Solution base kit
o
1 x AX10 base
o
4 x Pallet sensors
l
1 x AX10 Palletizing Solution Column
o
1 x Linear axis (1500 mm stroke)
o
1 x Linear axis motor
o
1 x Linear axis controller
o
2 x Status lights
l
1 x Box detection sensor kit
o
1 x Box detection sensor
o
1 x Box sensor bracket with screws
o
1 x 5 m box sensor cable (already channeled through the column)
l
1 x Robot cable management kit
o
4 x 500 mm cable clips
o
8 x 190 mm cable ties
l
1 x Material Handling Copilot software license dongle
l
1 x Set of four (4) casters with screws
l
1 x 12 mm air tube (5 m), already channeled through the column
l
1 x 10 mm double air tube (5 m), already channeled through the cable carrier
l
1 x Installation hardware kit
o
4 x M10 x 25 mm thread-locking hex head cap screws with flat washers
o
4 x M8 x 25 mm socket head cap screws with serrated Belleville washers
o
4 x M12 x 25 mm hex serrated head flange screws
o
3 x M6 x 12 mm socket head cap screws with external-tooth lock washers
o
6 x M12 x 55 mm socket head cap screws
o
6 x 1/2 in x 3-3/4 in concrete wedge anchors with serrated flange nuts
l
1 x 4-port USBhub
l
1 x USB-to-Ethernet adapter
l
1 x Ethernet cable (300 mm)
