AX10 Palletizing Solution
If a TCP offset is added in the X or Y directions, the software will act as if an extra reach bracket is being used.
Bracket representation
Height Width Length Direction
31.5 mm 75 mm Same length as TCP offset (X, Y) Same direction as TCP offset (X, Y)
