232 Rockwell Automation Publication 2198-UM005C-EN-P - February 2022
Appendix C Motor Control Feature Support
Phase Loss Detection Current Example
In this example, a 2198-C1004-ERS drive is paired with a TLP-A070-020 motor
with 1.65 A rms continuous current. Use the phase-loss detection equation and
table to calculate the initial minimum torque-proving current as a percentage
of motor rated current. Depending on the unique characteristics of your
application, the required torque-proving current value can be larger than the
initial recommended value.
Figure 122 - Phase-loss Detection Equation
Table 105 - Recommended Phase-loss Detection Current
=
0.203 A
1.65 A
=
12.30%
motor rated current.
Rating from Table
Motor Rated Current
Drive Cat. No.
Phase-loss Detection Current, min
A, rms
2198-C1004-ERS 0.203
2198-C1007-ERS 0.330
2198-C1015-ERS 0.610
2198-C1020-ERS 0.879
2198-C2030-ERS 1.407
2198-C2055-ERS 2.891
2198-C2075-ERS 3.430
2198-C4004-ERS 0.117
2198-C4007-ERS 0.208
2198-C4015-ERS 0.376
2198-C4020-ERS 0.523
2198-C4030-ERS 0.838
2198-C4055-ERS 1.626
2198-C4075-ERS 1.976
