28 Rockwell Automation Publication 2198-UM005C-EN-P - February 2022
Chapter 2 Plan the Kinetix 5300 Drive System Installation
Table 7 - Kinetix 5300 UL/CSA Circuit Protection Specifications
Drive Cat. No.
AC Input Voltage,
nom
Phase
Bussmann Fuses
Cat. No.
Molded Case CB Cat. No.
2198-C1004-ERS
200…240V AC
Three phase
KTK-R-6 140U-D6D3-B40 and 140UT-D7D3-B40
2198-C1007-ERS KTK-R-10 140U-D6D3-B80 and 140UT-D7D3-B80
2198-C1015-ERS KTK-R-15 140U-D6D3-C12 and 140UT-D7D3-C12
2198-C1020-ERS KTK-R-25 140U-D6D3-C20 and 140UT-D7D3-C20
2198-C2030-ERS KTK-R-30 140U-D6D3-C30 and 140UT-D7D3-C30
2198-C2055-ERS LPJ-50SP 140G-G6C3-C50
2198-C2075-ERS LPJ-60SP 140G-G6C3-C60
2198-C4004-ERS
380…480V AC
KTK-R-3 140U-D6D3-B20 and 140UT-D7D3-B20
2198-C4007-ERS KTK-R-6 140U-D6D3-B40 and 140UT-D7D3-B40
2198-C4015-ERS KTK-R-12 140U-D6D3-B80 and 140UT-D7D3-B80
2198-C4020-ERS KTK-R-15 140U-D6D3-C12 and 140UT-D7D3-C12
2198-C4030-ERS KTK-R-25 140U-D6D3-C15 and 140UT-D7D3-C15
2198-C4055-ERS LPJ-30SP 140U-D6D3-C30 and 140UT-D7D3-C30
2198-C4075-ERS LPJ-35SP 140U-D6D3-C30 and 140UT-D7D3-C30
2198-C1004-ERS
100…120V AC
Single phase
KTK-R-6 140U-D6D2-B40 and 140UT-D7D2-B40
2198-C1007-ERS KTK-R-10 140U-D6D2-B80 and 140UT-D7D2-B80
2198-C1015-ERS KTK-R-15 140U-D6D2-C12 and 140UT-D7D2-C12
2198-C1020-ERS KTK-R-25 140U-D6D2-C20 and 140UT-D7D2-C20
2198-C1004-ERS
200…240V AC
KTK-R-6 140U-D6D2-B40 and 140UT-D7D2-B40
2198-C1007-ERS KTK-R-10 140U-D6D2-B80 and 140UT-D7D2-B80
2198-C1015-ERS KTK-R-15 140U-D6D2-C12 and 140UT-D7D2-C12
2198-C1020-ERS KTK-R-25 140U-D6D2-C20 and 140UT-D7D2-C20
Table 8 - Kinetix 5300 IEC (non-UL/CSA) Circuit Protection Specifications
Drive Cat. No.
AC Input 
Voltage, nom
Phase
DIN gG 
Fuses
Amps, max
Miniature CB 
Cat. No.
Molded Case CB Cat. No.
2198-C1004-ERS
200…240V AC
Three phase
6 1489-M3C060 140U-D6D3-B40 and 140UT-D7D3-B40
2198-C1007-ERS 10 1489-M3C100 140U-D6D3-B80 and 140UT-D7D3-B80
2198-C1015-ERS 16 1489-M3C160 140U-D6D3-C12 and 140UT-D7D3-C12
2198-C1020-ERS 25 1489-M3C250 140U-D6D3-C20 and 140UT-D7D3-C20
2198-C2030-ERS 32 1489-M3C400 140U-D6D3-C30 and 140UT-D7D3-C30
2198-C2055-ERS 40 — 140G-G6C3-C50
2198-C2075-ERS 50 — 140G-G6C3-C60
2198-C4004-ERS
380…480V AC
2 1489-M3C030 140U-D6D3-B20 and 140UT-D7D3-B20
2198-C4007-ERS 6 1489-M3C060 140U-D6D3-B40 and 140UT-D7D3-B40
2198-C4015-ERS 12 1489-M3C100 140U-D6D3-B80 and 140UT-D7D3-B80
2198-C4020-ERS 16 1489-M3C130 140U-D6D3-C12 and 140UT-D7D3-C12
2198-C4030-ERS 25 1489-M3C200 140U-D6D3-C15 and 140UT-D7D3-C15
2198-C4055-ERS 32 1489-M3C350 140U-D6D3-C30 and 140UT-D7D3-C30
2198-C4075-ERS 32 1489-M3C400 140U-D6D3-C30 and 140UT-D7D3-C30
2198-C1004-ERS
100…120V AC
or
200…240V AC
Single phase
6 1489-M2C060 140U-D6D2-B40 and 140UT-D7D2-B40
2198-C1007-ERS 10 1489-M2C100 140U-D6D2-B80 and 140UT-D7D2-B80
2198-C1015-ERS 16 1489-M2C160 140U-D6D2-C12 and 140UT-D7D2-C12
2198-C1020-ERS 25 1489-M2C250 140U-D6D2-C20 and 140UT-D7D2-C20
