32 Rockwell Automation Publication 2198-UM005C-EN-P - February 2022
Chapter 2 Plan the Kinetix 5300 Drive System Installation
Because this cabinet size is considerably larger than what is necessary to house
the system components, it can be more efficient to provide a means of cooling
in a smaller cabinet. Contact your cabinet manufacturer for options available
to cool your cabinet.
Table 11 - Power Dissipation Specifications
Kinetix 5300 Drive
Cat. No.
AC Input,
nom
Usage as a % of Rated Power Output
(1)
(watts)
20% 40% 60% 80% 100%
2198-C1004-ERS
200…240V
three-phase
12 16 20 25 29
2198-C1007-ERS 14 19 24 30 37
2198-C1015-ERS 26 36 47 59 71
2198-C1020-ERS 35 52 71 91 112
2198-C2030-ERS 53 87 124 164 206
2198-C2055-ERS 87 139 193 250 308
2198-C2075-ERS 97 159 225 293 364
2198-C4004-ERS
380…480V
three-phase
16 21 26 31 36
2198-C4007-ERS 20 30 39 48 58
2198-C4015-ERS 33 48 62 78 93
2198-C4020-ERS 39 58 79 101 124
2198-C4030-ERS 57 89 123 157 193
2198-C4055-ERS 112 171 231 293 356
2198-C4075-ERS 134 204 273 344 417
2198-C1004-ERS
100…120V
single-phase
11 14 18 22 26
2198-C1007-ERS 12 17 21 27 32
2198-C1015-ERS 23 32 42 53 64
2198-C1020-ERS 30 44 59 77 96
2198-C1004-ERS
200…240V
single-phase
12 16 20 25 30
2198-C1007-ERS 14 19 24 30 37
2198-C1015-ERS 25 36 47 59 72
2198-C1020-ERS 35 52 72 92 115
(1) Internal shunt power is not included in the calculations and must be added based on utilization.
