Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

108 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Chapter 3 Programming and Parameters
Logic Group (continued)
L190 [Stp Logic Time 0]
L192 [Stp Logic Time 2]
L194 [Stp Logic Time 4]
L196 [Stp Logic Time 6]
L191 [Stp Logic Time 1]
L193 [Stp Logic Time 3]
L195 [Stp Logic Time 5]
L197 [Stp Logic Time 7]
PowerFlex 525 only.
Sets the time to remain in each step if the corresponding command word is set to “Step based on time”.
Values
Default: 30.0 s
Min/Max: 0.0/999.9 s
Display: 0.1 s
PF 525
L200 [Step Units 0]
L204 [Step Units 2]
L208 [Step Units 4]
L212 [Step Units 6]
L202 [Step Units 1]
L206 [Step Units 3]
L210 [Step Units 5]
L214 [Step Units 7]
32 bit parameter.
PowerFlex 525 only.
Sets the position in user-defined units the drive must reach at each step.
Values
Default: 0.00
Min/Max: 0.00/6400.00
Display: 0.01
32
PF 525
L201 [Step Units F 0]
L205 [Step Units F 2]
L209 [Step Units F 4]
L213 [Step Units F 6]
L203 [Step Units F 1]
L207 [Step Units F 3]
L211 [Step Units F 5]
L215 [Step Units F 7]
PowerFlex 525 only .
Sets the position in user-defined units (fractional portion) the drive must reach at each step.
Values
Default: Read Only
Min/Max: 0.00/0.99
Display: 0.01
PF 525
