Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001K-EN-E - August 2021 75
Chapter 3 Programming and Parameters
CustomView Parameter Group
PowerFlex 520-series drives include a CustomView parameter group for you to
store frequently used parameters for your application. See CustomView
Parameter Group on page 151 for more information.
Extruder
Language P030
Output Freq b001
Commanded Freq b002
Output Current b003
Motor NP Volts P031
Motor NP Hertz P032
Motor OL Current P033
Motor NP FLA P034
Motor NP Poles P035
Autotune P040
Accel Time 1 P041
Decel Time 1 P042
Minimum Freq P043
Maximum Freq P044
Stop Mode P045
Start Source 1 P046
Speed Reference1 P047
Relay Out1 Sel t076
Analog Out Sel t088
Analog Out High t089
Anlg Out Setpt t090
Anlg In 0-10V Lo t091
Anlg In 0-10V Hi t092
Anlg In4-20mA Lo t095
Anlg In4-20mA Hi t096
Anlg In mA Loss t097
Slip Hz Meter d375
Speed Feedback d376
Speed Feedback F d377
Encoder Speed d378
Preset Freq 0 A410
Stall Fault Time A492
Motor Fdbk Type A535
Encoder PPR A536
Pulse In Scale A537
Ki Speed Loop A538
Kp Speed Loop A539
Power Loss Mode A548
Half Bus Enable A549
Positioning
(1)
Language P030
Output Freq b001
Commanded Freq b002
Motor NP Volts P031
Motor NP Hertz P032
Motor OL Current P033
Motor NP FLA P034
Motor NP Poles P035
Autotune P040
Accel Time 1 P041
Decel Time 1 P042
Minimum Freq P043
Maximum Freq P044
Stop Mode P045
Start Source 1 P046
Speed Reference1 P047
DigIn TermBlk 02 t062
DigIn TermBlk 03 t063
DigIn TermBlk 05 t065
DigIn TermBlk 06 t066
Opto Out1 Sel t069
Opto Out2 Sel t072
Relay Out1 Sel t076
EM Brk Off Delay t086
EM Brk On Delay t087
Stp Logic 0 L180
Stp Logic 1 L181
Stp Logic 2 L182
Stp Logic 3 L183
Stp Logic 4 L184
Stp Logic 5 L185
Stp Logic 6 L186
Stp Logic 7 L187
Stp Logic Time 0 L190
Stp Logic Time 1 L191
Stp Logic Time 2 L192
Stp Logic Time 3 L193
Stp Logic Time 4 L194
Stp Logic Time 5 L195
Stp Logic Time 6 L196
Stp Logic Time 7 L197
Step Units 0 L200
Step Units 1 L202
Step Units 2 L204
Step Units 3 L206
Step Units 4 L208
Step Units 5 L210
Step Units 6 L212
Step Units 7 L214
Slip Hz Meter d375
Speed Feedback d376
Encoder Speed d378
Units Traveled H d388
Units Traveled L d389
Preset Freq 0 A410
Preset Freq 1 A411
Preset Freq 2 A412
Preset Freq 3 A413
Preset Freq 4 A414
Preset Freq 5 A415
Preset Freq 6 A416
Preset Freq 7 A417
Preset Freq 8 A418
Jog Frequency A431
Jog Accel/Decel A432
DB Threshold A438
S Curve % A439
Motor Fdbk Type A535
Encoder PPR A536
Pulse In Scale A537
Ki Speed Loop A538
Kp Speed Loop A539
Bus Reg Enable A550
Positioning Mode A558
Counts Per Unit A559
Enh Control Word A560
Find Home Freq A562
Find Home Dir A563
Encoder Pos Tol A564
Pos Reg Filter A565
Pos Reg Gain A566
Textile/Fiber
Language P030
Output Freq b001
Commanded Freq b002
Motor NP Volts P031
Motor NP Hertz P032
Motor OL Current P033
Motor NP FLA P034
Motor NP Poles P035
Autotune P040
Accel Time 1 P041
Decel Time 1 P042
Minimum Freq P043
Maximum Freq P044
Stop Mode P045
Start Source 1 P046
Speed Reference1 P047
DigIn TermBlk 02 t062
DigIn TermBlk 03 t063
Opto Out1 Sel t069
Opto Out2 Sel t072
Relay Out1 Sel t076
Anlg In 0-10V Lo t091
Anlg In 0-10V Hi t092
Anlg In4-20mA Lo t095
Anlg In4-20mA Hi t096
Anlg In mA Loss t097
Slip Hz Meter d375
Fiber Status d390
Preset Freq 0 A410
Jog Frequency A431
Jog Accel/Decel A432
S Curve % A439
Reverse Disable A544
Power Loss Mode A548
Half Bus Enable A549
Bus Reg Enable A550
Max Traverse A567
Traverse Inc A568
Traverse Dec A569
P Jump A570
Sync Time A571
Speed Ratio A572
(1) This AppView parameter group is specific to PowerFlex 525 drives only.
Parameters Group (Continued)
Custom Group
This group can store up to 100 parameters.
