Preface
About This Publication
The purpose of this manual is to provide you with the basic information
needed to install, start-up and troubleshoot the PowerFlex® 520-Series
Adjustable Frequency AC Drive.
Download Firmware, AOP,
EDS, and Other Files
Download firmware, associated files (such as AOP, EDS, and DTM), and access
product release notes from the Product Compatibility and Download Center at
rok.auto/pcdc
.
See Download Files
on page 10 to download the files for your PowerFlex 525
drive.
Summary of Changes
This publication contains the following new or updated information. This list
includes substantive updates only and is not intended to reflect all changes.
Topic Page
Summary of Changes 9
Additional Resources 10
Manual Conventions 11
Drive Frame Sizes 12
General Precautions 13
Catalog Number Explanation 14
Topic Page
Removed column “Min Enclosure Vol” from Fuses and Circuit Breaker tables 24…27
Updated C2 and C3 categories external requirements in PowerFlex 520-Series RF Emission
Compliance and Installation Requirements table
54
Added footnote on EMC enclosure dimension 55
Corrected PCR with ID 1018 on description of P043 [Minimum Freq] 85
Corrected PCR with ID 1539 on fractional parameters.
• Added t071 [Opto Out1 LevelF] and t074 [Opto Out2 LevelF]
• Added t078 [RelayOut1 LevelF] and t083 [RelayOut2 LevelF]
• Added L201 [Step Units F 0], L203 [Step Units F 1], L205 [Step Units F 2], L207 [Step Units F
3], L209 [Step Units F 4], L2011 [Step Units F 5], L213 [Step Units F6], and L215 [Step Units F 7]
• Updated d366 [Timer StatusF]
• Updated d377 [Speed Feedback F]
• Updated d379 [Encoder Speed F]
• Updated d389 [Units Traveled L]
92
94
108
109
110
111
112
Corrected PCR with ID 1541 on parameter reference t105 [Safety Open En] for Fault F059 160
Added Efficiency Class certification based on Ecodesign Regulation (EU) 2019/1781 165
Updated Input Current Scaling section and table to improve clarity 171
Added column “For 150 m” to EMC Line Filters table 175
