220 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Appendix E Encoder/Pulse Train Usage and Position StepLogic Application
Therefore, using a 1024 PPR quadrature encoder will give a speed resolution of
0.49 Hz.
Positioning Overview The PowerFlex 525 drive includes a simple position regulator which can be
used in a variety of position applications without the need for multiple limit
switches or photo-eyes. This can be used as a standalone controller for simple
applications (up to 8 positions) or in conjunction with a controller for more
flexibility.
Please note that this is not intended to replace high end servo controllers or
any application that needs high bandwidth or very high torque at low speeds.
Common Guidelines for All
Applications
The position regulator can be configured for operation appropriate for a
variety of applications. Certain parameters will need to be adjusted in all cases.
P047
[Speed Reference1] must be set to 16 “Positioning”.
A535
[Motor Fdbk Type] must be set to the match the feedback device.
Positioning mode must use A535
[Motor Fdbk Type] option 4.
A535
[Motor Fdbk Type] Options
0 “None” indicates no encoder is used. This can not be used for
positioning.
1 “Pulse Train” is a single channel input, no direction, speed feedback
only. This should not be used for positioning. The Single Channel
selection is similar to a Pulse Train, but uses the standard encoder
scaling parameters.
2 “Single Chan” is a single channel input, no direction, speed feedback
only. This should not be used for positioning. Single channel uses the
standard encoder scaling parameters.
3 “Single Check” is a single channel input with encoder signal loss
detection. The drive will fault if it detects that the input pulses do not
match the expected motor speed. This should not be used for
positioning.
4 “Quadrature” is a dual channel encoder input with direction and
speed from the encoder. This may be used for positioning control.
5 “Quad Check” is a dual channel encoder with encoder signal loss
detection. The drive will fault if it detects that the encoder speed does
not match the expected motor speed.
A544
[Reverse Disable] should be set to 0 “Rev Enabled” to allow bidirectional
movement necessary for position control.
P039
[Torque Perf Mode] default setting is 1 “SVC”. However, any mode can be
used to improve the low speed torque for positioning applications. For best
