Rockwell Automation Allen-Bradley PowerFlex 520 Series - Adapter Plate Dimensions

Rockwell Automation Publication 520-UM001K-EN-E - August 2021 197
Appendix B Accessories and Dimensions
EMC Line Filter – Frame E
Adapter Plate Dimensions
Bulletin 160 to PowerFlex 520-Series Mounting Adapter Plate Dimensions
80.0 (3.15)
28.0 (1.10)
155.0 (6.10)
110.0 (4.33)
110.0 (4.33)
33.0 (1.30)
28.0 (1.10)33.0 (1.30)
375.0
(14.76)
375.0
(14.76)
390.0
(15.35)
ø5.5 (ø0.22)
5.5 (0.22)
Dimensions are in millimeters and (inches)
Dimensions are in millimeters and (inches)
Frame A
25-MAP-FA
Frame B
25-MAP-FB
80.0 (3.15)
39.2 (1.54)
20.2 (0.80)
198.0 (7.80)
92.0 (3.62)
39.2 (1.54)
20.2 (0.80)
240.0 (9.45)
