Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001K-EN-E - August 2021 63
Chapter 2 Start Up
Smart Startup with Basic
Program Group Parameters
The PowerFlex 520-series drive is designed so that start up is simple and
efficient. The Basic Program Group contains the most commonly used
parameters. See Programming and Parameters
on page 69 for detailed
descriptions of the parameters listed here and the full list of available
parameters.
Basic Program Group Parameters
= Stop drive before changing this parameter.
= Parameter is specific to PowerFlex 525 drives only.
No. Parameter Min/Max Display/Options Default
P030
[Language] 1/15 1 = English
2= Français
3= Español
4= Italiano
5= Deutsch
6= Reserved
7= Português
8= Reserved
9= Reserved
10= Reserved
11 = Reserved
12 = Polish
13 = Reserved
14= Turkish
15 = Czech
1
Selects the language displayed.
Important: The setting takes effect after the
drive is power cycled.
P031
[Motor NP Volts]
10V (for 200V Drives), 20V
(for 400V Drives), 25V (for
600V Drives)/Drive Rated
Volts
1V Based on Drive Rating
Sets the motor nameplate rated volts.
P032 [Motor NP Hertz] 15/500 Hz
1 Hz 60 Hz
Sets the motor nameplate rated frequency.
P033
[Motor OL Current] 0.0/(Drive Rated Amps x 2)
0.1 A Based on Drive Rating
Sets the motor nameplate overload current.
P034
[Motor NP FLA] 0.0/(Drive Rated Amps x 2)
0.1 A Drive Rated Amps
Sets the motor nameplate FLA.
P035
[Motor NP Poles] 2/40
14
Sets the number of poles in the motor.
P036 [Motor NP RPM] 0/24000 rpm
1 rpm 1750 rpm
Sets the rated nameplate rpm of motor.
P037
[Motor NP Power] 0.00/Drive Rated Power
0.01 kW Drive Rated Power
Sets the motor nameplate power. Used in PM
regulator.
P039
[Torque Perf
Mode]
0/4
0 = “V/Hz”
1 = “SVC”
2 = “Economize”
3 = “Vector”
(1)
4 = “PM Control”
(1)(2)(3)
5 = “SynRM”
1
Selects the motor control mode.
(1) Setting is specific to PowerFlex 525 drives only.
(2) Setting is available in PowerFlex 525 FRN 5.xxx
and later.
(3) When P039 [Torque Perf Mode] is set to 4 and
A535
[Motor Fdbk Type] is set to 0, 1, 2 or 3, the
drive is in open loop PM motor control mode.
When P039 [Torque Perf Mode] is set to 4 and
A535
[Motor Fdbk Type] is set to 4 or 5, the
drive is in closed loop PM motor control mode.
P040
[Autotune] 0/2
0 = “Ready/Idle”
1 = “Static Tune”
2 = “Rotate Tune”
0
Enables a static (not spinning) or dynamic
(motor spinning) autotune.
P041
[Accel Time 1] 0.00/600.00 s
0.01 s 10.00 s
Sets the time for the drive to accel from 0 Hz
to [Maximum Freq].
PF 525
PF 525
