64 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Chapter 2 Start Up
P042
[Decel Time 1] 0.00/600.00 s
0.01 s 10.00 s
Sets the time for the drive to decel from
[Maximum Freq] to 0 Hz.
P043 [Minimum Freq] 0.00/500.00 Hz
0.01 Hz 0.00 Hz
Sets the lowest frequency the drive outputs.
P044 [Maximum Freq] 0.00/500.00 Hz
0.01 Hz 60.00 Hz
Sets the highest frequency the drive outputs.
P045
[Stop Mode] 0/11
0= “Ramp, CF”
(1)
1= “Coast, CF”
(1)
2= “DC Brake, CF”
(1)
3= “DCBrkAuto,CF”
(1)
4= “Ramp”
5= “Coast”
6= “DC Brake”
7= “DC BrakeAuto”
8= “Ramp+EM B,CF”
(1)
9= “Ramp+EM Brk”
10= “PointStp,CF”
(1)
11= “PointStop”
0
Stop command for normal stop.
Important: I/O Terminal 01 is always a stop
input. The stopping mode is determined by the
drive setting.
Important: The drive is shipped with a jumper
installed between I/O Terminals 01 and 11.
Remove this jumper when using I/O Terminal
01 as a stop or enable input.
(1) Stop input also clears active fault.
P046,
P048,
P050
[Start Source 1] 1/5
1 = “Keypad”
(1)
2 = “DigIn TrmBlk”
(2)
3 = “Serial/DSI”
4 = “Network Opt”
5 = “EtherNet/IP”
(3)
P046 = 1
P048 = 2
P050 = 3 (PowerFlex 523)
5 (PowerFlex 525)
Sets the default control scheme used to start
the drive unless overriden by P048 [Start
Source 2] or P050 [Start Source 3].
(1) When active, the Reverse key is also active
unless disabled by A544 [Reverse Disable].
(2) If “DigIn TrmBlk” is selected, ensure that the
digital inputs are properly configured.
(3) Setting is specific to PowerFlex 525 drives only.
P047,
P049,
P051
[Speed
Reference1]
1/16
1= “Drive Pot”
2= “Keypad Freq”
3= “Serial/DSI”
4= “Network Opt”
5= “0-10V Input”
6= “4-20mA Input”
7= “Preset Freq”
8= “Anlg In Mult”
(1)
9= “MOP”
10= “Pulse Input”
11= “PID1 Output”
12= “PID2 Output”
(1)
13= “Step Logic”
(1)
14= “Encoder”
(1)
15= “EtherNet/IP”
(1)
16= “Positioning”
(1)
P047 = 1
P049 = 5
P051 = 3 (PowerFlex 523)
15 (PowerFlex 525)
Sets the default speed command of the drive
unless overridden by P049 [Speed Reference2]
or P051 [Speed Reference3].
(1) Setting is specific to PowerFlex 525 drives only.
P052
[Average kWh
Cost]
0.00/655.35
0.01 0.00
Sets the average cost per kWh.
P053
[Reset To Defalts] 0/4
0 = “Ready/Idle”
1 = “Param Reset”
2 = “Factory Rset”
3 = “Power Reset”
4 = “Module Reset”
(1)(2)(3)
0
Resets parameters to their factory defaults
values. After a Reset command, the value of
this parameter returns to zero.
(1) Power cycle of the drive, NO parameters are
reset.
(2) Setting is available in PowerFlex 525 FRN 5.xxx
and later.
(3) Setting is available in PowerFlex 523 FRN 3.xxx
and later.
Basic Program Group Parameters (Continued)
= Stop drive before changing this parameter.
= Parameter is specific to PowerFlex 525 drives only.
No. Parameter Min/Max Display/Options Default
