Page #109 background imageLoading...
Page #109 background image
Rockwell Automation Publication 520-UM001K-EN-E - August 2021 109
Chapter 3 Programming and Parameters
Advanced Display Group
d360 [Analog In 0-10V] Related Parameter(s): t091, t092
Displays the 0…10V analog input as a percent of full scale.
Values
Default: Read Only
Min/Max: 0.0/100.0%
Display: 0.1%
d361 [Analog In 4-20mA] Related Parameter(s): t095, t096
Displays the 4…20 mA analog input as a percent of full scale.
Values
Default: Read Only
Min/Max: 0.0/100.0%
Display: 0.1%
d362 [Elapsed Time-hr] Related Parameter(s): A555
Displays the total elapsed powered-up time (in hours) since timer reset. The timer stops when it reaches the maximum value.
Values
Default: Read Only
Min/Max: 0/32767 hr
Display: 1 hr
d363 [Elapsed Time-min] Related Parameter(s): d362, A555
Displays the total elapsed powered-up time (in minutes) since timer reset. Resets to zero when maximum value is reached and increments d362 [Elapsed Time-hr] by one.
Values
Default: Read Only
Min/Max: 0.0/60.0 min
Display: 0.1 min
d364 [Counter Status]
Displays the current value of the counter if enabled.
Values
Default: Read Only
Min/Max: 0/65535
Display: 1
d365 [Timer Status]
32 bit parameter.
Displays the current value of the timer if enabled.
Values
Default: Read Only
Min/Max: 0.0/9999.0 s
Display: 0.1 s
32
d366 [Timer StatusF]
Displays the current value of the timer (fractional portion) if enabled.
Values
Default: Read Only
Min/Max: 0.0/0.9 s
Display: 0.1 s
