98 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Chapter 3 Programming and Parameters
Terminal Block Group (continued)
t096 [Anlg In4-20mA Hi] Related Parameter(s): P044, t095
Stop drive before changing this parameter.
Sets the percentage (based on 4…20 mA) of input current applied to the 4…20 mA analog input used to represent P044 [Maximum Freq].
Analog inversion can be accomplished by setting this value smaller than t095 [Anlg In4-20mA Lo].
Values
Default: 100.0%
Min/Max: 0.0/200.0%
Display: 0.1%
t097 [Anlg In mA Loss] Related Parameter(s): P043, P044, A426, A427
Sets the response to a loss of input. When the 4…20 mA input is used for any reference, any input less than 2 mA is reported as a signal loss. Input must exceed 3 mA for
the signal loss condition to end.
If enabled, this function affects any input that is being used as a speed reference or PID reference or PID setpoint in the drive.
Options
0 “Disabled” (Default)
1 “Fault (F29)”
2“Stop”
3“Zero Ref”
4“Min Freq Ref”
5“Max Freq Ref”
6“Key Freq Ref”
7“MOP Freq Ref”
8 “Continu Last”
t098 [Anlg Loss Delay] Related Parameter(s): t094, t097
Sets the length of time after power-up during which the drive detects no analog signal loss.
Response to an analog signal loss is set in t094 or t097 [Analog In x Loss].
Values
Default: 0.0 s
Min/Max: 0.0 /20.0 s
Display: 0.1 s
t100 [Sleep-Wake Sel] Related Parameter(s): t101, t102, t103
Drive “sleeps” if the appropriate analog input drops below the set t101 [Sleep Level] for the time set in t102 [Sleep Time] and the drive is running. When entering sleep mode
the drive ramps to zero and the run indicator on the keypad display flashes to indicate the drive is in “sleep” mode.
When the appropriate analog input rises above the set [Wake Level], the drive “wakes” and ramps to the commanded frequency.
Inversion can be accomplished by setting [Sleep Level] to a higher setting than t103
[Wake Level].
Options
0 “Disabled” (Default)
1 “0-10V Input” Sleep enabled from 0…10V Analog Input 1
2 “4-20mA Input” Sleep enabled from 4…20 mA Analog Input 2
3 “Command Freq” Sleep enabled based on drive commanded frequency
t101 [Sleep Level]
Sets the analog input level the drive must reach to enter sleep mode.
Values
Default: 10.0%
Min/Max: 0.0/100.0%
Display: 0.1%
ATTENTION: Enabling the Sleep-Wake function can cause unexpected machine operation during the Wake mode.
Equipment damage and/or personal injury can result if this parameter is used in an inappropriate application. In addition,
all applicable local, national and international codes, standards, regulations or industry guidelines must be considered.
