Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

94 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Chapter 3 Programming and Parameters
Values
Default:
Relay Out1 Sel:
Relay Out2 Sel:
0
2
Min/Max: 0/31
Display: 1
Programmable Relay Outputs (Continued)
t077 [Relay Out1 Level] Related Parameter(s): t076, t081
t082 [Relay Out2 Level]
PowerFlex 525 only.
32 bit parameter.
Determines the on/off point for the output relay when t076 or t081 [Relay Outx Sel] is set to the values shown below.
Values
Default: 0.0
Min/Max: 0.0/9999.0
Display: 0.1
PF 525
32
Min/Max Value Range Based On [Relay Outx Sel] Setting
6: 0...500 Hz 10: 0...100% 16: 0.1...9999 s 20: 0/1
7: 0...180% 11: 0/1 17: 1...9999 counts 26: 0...150%
8: 0...815V 13: 0...800 18: 0...180 °C –
t078 [RelayOut1 LevelF]
t083 [RelayOut2 LevelF]
PowerFlex 525 only.
Determines the on/off point (fractional portion) for the output relay.
Values
Default: Read Only
Min/Max: 0.0/0.9 s
Display: 0.1 s
PF 525
t079 [Relay 1 On Time]
t084 [Relay 2 On Time]
PowerFlex 525 only.
Sets the delay time before Relay energizes after required condition is met.
Values
Default: 0.0 s
Min/Max: 0.0/600.0 s
Display: 0.1 s
PF 525
t080 [Relay 1 Off Time]
t085 [Relay 2 Off Time]
PowerFlex 525 only.
Sets the delay time before Relay de-energizes after required condition ceases.
Values
Default: 0.0 s
Min/Max: 0.0/600.0 s
Display: 0.1 s
PF 525
