Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

112 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Chapter 3 Programming and Parameters
Advanced Display Group (continued)
d387 [Position Status]
PowerFlex 525 only.
Displays the present operating condition of the drive. When in Positioning mode, Bit 1 indicates positive or negative position in relation to Home.
Values
Default: Read Only
Min/Max: 0000/1111
Display: 0000
PF 525
1 = Condition True, 0 = Condition False
Dir Positive Digit 1
At Position Digit 2
At Home Digit 3
Drive Homed Digit 4
Not Used
d388 [Units Traveled H] Related Parameter(s): d387
Stop drive before changing this parameter.
32 bit parameter.
PowerFlex 525 only.
Displays the number of user-defined units traveled from the home position. See d387 [Position Status] for direction of travel.
Values
Default: Read Only
Min/Max: 0/64000
Display: 1
32
PF 525
d389 [Units Traveled L] Related Parameter(s): d387
Stop drive before changing this parameter.
PowerFlex 525 only.
Displays the number of user-defined units (fractional portion) traveled from the home position. See d387 [Position Status] for direction of travel.
Values
Default: Read Only
Min/Max: 0.00/0.99
Display: 0.01
PF 525
d390 [Fiber Status]
Present status of the Fibers features.
Values
Default: Read Only
Min/Max: 0000/1111
Display: 0000
1 = Condition True, 0 = Condition False
Sync Hold Digit 1
Sync Ramp Digit 2
Traverse On Digit 3
Traverse Dec Digit 4
Not Used
d391 [Stp Logic Status] Related Parameter(s): P047, L180-L187
PowerFlex 525 only.
Displays the current step of the StepLogic profile as defined by parameters L180...L187 [Step Logic x] when P047 [Speed Reference1] is set to 13 “Step Logic” or 16
“Positioning”.
Values
Default: Read Only
Min/Max: 0/8
Display: 1
PF 525
