Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001K-EN-E - August 2021 113
Chapter 3 Programming and Parameters
Advanced Display Group (continued)
d392 [RdyBit Mode Act] Related Parameter(s): A574
(With PowerFlex 525 FRN 3.xxx and later.)
(With PowerFlex 523 FRN 3.xxx and later.)
Displays the value of A574 [RdyBit Mode Cfg].
Values
Default: Read Only
Min/Max: 0/1
Display: 1
d393 [Drive Status 2]
(With PowerFlex 525 FRN 5.xxx and later.)
(With PowerFlex 523 FRN 3.xxx and later.)
Displays the present operating condition of the drive.
(1) Bit status is specific to PowerFlex 525 drives only.
Values
Default: Read Only
Min/Max: 0/65535
Display: 1
000000000 x 0000 xx
10 01234567891112131415
1 = Condition True
0 = Condition False
x = Reserved
Bit #
Jogging
Flux Braking
Motor Overld
AutoRst Ctdn
DC Braking
At Freq
Auto Tuning
EM Braking
Curr Limit
Safety S1
(1)
Safety S2
(1)
F111 Status
(1)
SafeTqPermit
(1)
Nibble 1Nibble 2Nibble 3Nibble 4
* Enhanced Control Option Only.
d394 [Dig Out Status]
(With PowerFlex 525 FRN 5.xxx and later.)
(With PowerFlex 523 FRN 3.xxx and later.)
Displays relay output and opto output status.
Values
Default: Read Only
Min/Max: 0/15
Display: 1
Rly1 Status Digit 1
Rly2 Status
(1)
Digit 2
(1) Setting is specific to PowerFlex 525 drives only.
Opto1 Status
(1)
Digit 3
Opto2 Status
(1)
Digit 4
Not Used
Status Bit Value = 0 Bit Value = 1
Relay 1 status (Normally Open) Not activated (Relay 1 open) Activated (Relay 1 closed)
Relay 2 status (Normally Closed) Not activated (Relay 2 closed) Activated (Relay 2 open)
Opto 1 status Not activated Activated
Opto 2 status Not activated Activated
