Rockwell Automation Publication 520-UM001K-EN-E - August 2021 27
Chapter 1 Installation/Wiring
(1) Normal Duty (ND) and Heavy Duty (HD) ratings are available for this drive.
(2) When the drive is controlling motors with lower amp ratings, refer to the drive nameplate for drive input current rating.
(3) The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. SeeSee the Use of Motor Protection Circuit Breakers with Variable-Frequency Drives Application Techniques,
publication 140M-AT002
.
(4) Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip.
(5) Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 480Y/277 and 600Y/347 AC input. Not UL listed for use on 480V or 600V Delta/Delta, corner ground, or high-resistance
ground systems.
(6) When used with the 140M circuit breaker, the 25A-E9P9104 must be installed in a ventilated or non-ventilated enclosure with the minimum size of 457.2 x 457.2 x 269.8 mm (18 x 18 x 10.62 in.).
(7) When using a Manual Self-Protected (Type E) Combination Motor Controller with this drive power rating, the drive must be installed in a ventilated or non-ventilated enclosure with the minimum
volume specified in this column. Application specific thermal considerations may require a larger enclosure.
(8) Circuit breaker selection is not available for this drive rating.
525...600V 3-Phase Input Protection Devices – Frames A...E
Catalog No.
(1)
Output Ratings Input Ratings
Frame Size
Contactor
Catalog No.
IEC Applications (Non-UL) UL Applications
PF 523 PF 525
ND HD
Amps
kVA
Max
Amps
(2)
Fuses (Rating) Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Max. 140U/140G 140M Class / Catalog No. 140U/140G
140M
(3)(4)(5)
25A-E0P9N104 25B-E0P9N104 0.5 0.4 0.5 0.4 0.9 1.4 1.2 A 100-C09 3 6 140U-D6D3-B20 140M-C2E-B25 CLASS RK5, CC, J, or T / DLS-R-6
–
(8)
140M-C2E-B25
25A-E1P7N104 25B-E1P7N104 1.0 0.75 1.0 0.75 1.7 2.6 2.3 A 100-C09 3 6 140U-D6D3-B30 140M-C2E-B25 CLASS RK5, CC, J, or T / DLS-R-6
–
(8)
140M-C2E-B25
25A-E3P0N104 25B-E3P0N104 2.0 1.5 2.0 1.5 3.0 4.3 3.8 A 100-C09 6 10 140U-D6D3-B50 140M-C2E-B40 CLASS RK5, CC, J, or T / DLS-R-10
–
(8)
140M-C2E-B40
25A-E4P2N104 25B-E4P2N104 3.0 2.2 3.0 2.2 4.2 6.1 5.3 A 100-C09 10 16 140U-D6D3-B80 140M-C2E-B63 CLASS RK5, CC, J, or T / DLS-R-15
–
(8)
140M-D8E-B63
25A-E6P6N104 25B-E6P6N104 5.0 4.0 5.0 4.0 6.6 9.1 8.0 B 100-C09 10 20 140U-D6D3-C10 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-20
–
(8)
140M-D8E-C10
25A-E9P9N104 25B-E9P9N104 7.5 5.5 7.5 5.5 9.9 12.8 11.2 C 100-C16 16 25 140U-D6D3-C15 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-25
–
(8)
140M-D8E-C16
(6)
25A-E012N104 25B-E012N104 10.0 7.5 10.0 7.5 12.0 15.4 13.5 C 100-C23 20 32 140U-D6D3-C20 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-30
–
(8)
140M-D8E-C16
25A-E019N104 25B-E019N104 15.0 11.0 15.0 11.0 19.0 27.4 24.0 D 100-C30 32 50 140G-G6C3-C30 140M-F8E-C25 CLASS CC, J, or T / 50
–
(8)
140M-F8E-C25
25A-E022N104 25B-E022N104 20.0 15.0 15.0 11.0 22.0 31.2 27.3 D 100-C30 35 63 140G-G6C3-C35 140M-F8E-C32 CLASS CC, J, or T / 60
–
(8)
140M-F8E-C32
25A-E027N104 25B-E027N104 25.0 18.5 20.0 15.0 27.0 28.2 24.7 E 100-C30 35 50 140G-G6C3-C35 140M-F8E-C32 CLASS CC, J, or T / 50
–
(8)
140M-F8E-C32
25A-E032N104 25B-E032N104 30.0 22.0 25.0 18.5 32.0 33.4 29.2 E 100-C37 40 63 140G-G6C3-C50 140M-F8E-C32 CLASS CC, J, or T / 60
–
(8)
140M-F8E-C32
