120 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Chapter 3 Programming and Parameters
Advanced Program Group (continued)
A456 [PID 1 Trim Hi]
A468 [PID 2 Trim Hi]
PowerFlex 525 only.
Scales the upper value of the trim frequency when trim is active.
Values
Default: 60.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
PF 525
A457 [PID 1 Trim Lo]
A469 [PID 2 Trim Lo]
PowerFlex 525 only.
Scales the lower value of the trim frequency when trim is active.
Values
Default: 0.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
PF 525
A458 [PID 1 Trim Sel]
A470 [PID 2 Trim Sel]
PowerFlex 525 only.
Stop drive before changing this parameter.
Sets the PID output as trim to the source reference.
Options
0 “Disabled” (Default) PID Trim is disabled.
1 “TrimOn Pot”
2 “TrimOn Keypd”
3 “TrimOn DSI”
4 “TrimOn NetOp”
5 “TrimOn 0-10V”
6 “TrimOn 4-20”
7 “TrimOn Prset”
8 “TrimOn AnMlt”
(1)
9 “TrimOn MOP”
10 “TrimOn Pulse”
11 “TrimOn Slgic”
(1)
12 “TrimOn Encdr”
(1)
13 “TrimOn ENet”
(1)
(1) Setting is specific to PowerFlex 525 drives only.
PF 525
