Rockwell Automation Allen-Bradley PowerFlex 520 Series - Page 146

146 Rockwell Automation Publication 520-UM001K-EN-E - August 2021
Chapter 3 Programming and Parameters
Fault and Diagnostic Group (continued)
F687 [HW Addr 1]
F688 [HW Addr 2]
F689 [HW Addr 3]
F690 [HW Addr 4]
F691 [HW Addr 5]
F692 [HW Addr 6]
PowerFlex 525 only.
Shows the MAC address for the embedded EtherNet/IP interface.
Values
Default: Read Only
Min/Max: 0/255
Display: 1
PF 525
F693 [EN IP Addr Act 1]
F694 [EN IP Addr Act 2]
F695 [EN IP Addr Act 3]
F696 [EN IP Addr Act 4]
PowerFlex 525 only.
Shows the actual IP address used by the embedded EtherNet/IP interface at the time. This indicates 0 if no address is set.
Values
Default: Read Only
Min/Max: 0/255
Display: 1
PF 525
255.255.255.255
[EN IP Addr Act 1]
[EN IP Addr Act 2]
[EN IP Addr Act 3]
[EN IP Addr Act 4]
F697 [EN Subnet Act 1]
F698 [EN Subnet Act 2]
F699 [EN Subnet Act 3]
F700 [EN Subnet Act 4]
PowerFlex 525 only.
Shows the actual subnet mask used by the embedded EtherNet/IP interface at the time. This will indicate 0 if no address is set.
Values
Default: Read Only
Min/Max: 0/255
Display: 1
PF 525
255.255.255.255
[EN Subnet Act 1]
[EN Subnet Act 2]
[EN Subnet Act 3]
[EN Subnet Act 4]
