60 Rockwell Automation Publication 7000-UM202H-EN-P - November 2023
Chapter 2 Power Component Definition and Maintenance
Figure 47 - 3300/4160V Four Device PowerCage Module (heatsink model)
Figure 48 - 3300/4160V Four Device Rectifier PowerCage Module (with SPS Boards installed)
Pivot Plate
Matched Set
Two SGCTs
Matched Set
Two SGCTs
Heatsink
Module Housing
Temperature Feedback
Clamp Head
Pivot Plate
Matched Set
Two SGCTs
SPS Mounting Assembly with
Temperature Feedback Board
Matched Set
Two SGCTs
Clamp Head
Heatsink
SPS Mounting Board Assembly without
Temperature Feedback Board
Module Housing
To Next Page
