Rockwell Automation PowerFlex 7000 User Manual

Rockwell Automation Publication 7000-UM202H-EN-P - November 2023 61
Chapter 2 Power Component Definition and Maintenance
Figure 49 - 6600V Six Device PowerCage Module (heatsink model)
Figure 50 - 6600V Six Device PowerCage Module (with SPS Boards installed)
Pivot Plate
Matched Set
Three SGCTs
Matched Set
Three SGCTs
Clamp Head
Heatsink
Temperature Feedback Board
Module Housing
Pivot Plate
Matched Set
Three SGCTs
Matched Set
Three SGCTs
Clamp Head
Heatsink
SPS Mounting Assembly with
Temperature Feedback Board
SPS Mounting Assembly without
Temperature Feedback Board
Module
Housing
