Roland JD-XA - 22: Chorus (Chorus); 23: Flanger (Flanger)

33
Eects
22: Chorus
(Chorus)
This is a stereo chorus. A lter is provided so that you can adjust the
timbre of the chorus sound.
L in
R in
Chorus
Chorus
L out
R out
2-Band
EQ
2-Band
EQ
Balance W
Balance W
Balance D
Balance D
Parameter Value Explanation
Filter Type OFF, LPF, HPF
Type of lter
OFF: no lter is used
LPF: cuts the frequency range above
the Cuto
HPF: cuts the frequency range
below the Cuto
Cof Freq
(Cuto Freq)
200–8000 Hz
Center frequency when using the
lter to cut a specic frequency
range
Pre Delay 0.0–100.0 ms
Adjusts the delay time from the
direct sound until the chorus sound
is heard.
Sync Hz, NOTE
Hz: The Rate value is specied in Hz.
NOTE: The Rate value is specied as
a note value.
Rate #
0.05–10.00 Hz,
note
Rate of modulation
Depth 0–127 Depth of modulation
Phase 0–180 deg Spatial spread of the sound
Low Gain -15–+15 dB Amount of low-range boost/cut
High Gain -15–+15 dB Amount of high-range boost/cut
Balance #
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the chorus sound (W)
Level 0–127 Output volume
23: Flanger
(Flanger)
This is a stereo anger (The LFO has the same phase for left and
right.).
It produces a metallic resonance that rises and falls like a jet
airplane taking o or landing.
A lter is provided so that you can adjust the timbre of the anged
sound.
R in
R out
L in
L out
Flanger
Feedback
Feedback
Flanger
Balance W
Balance D
Balance W
Balance D
2-Band
EQ
2-Band
EQ
Parameter Value Explanation
Filter Type OFF, LPF, HPF
Type of lter
OFF: no lter is used
LPF: cuts the frequency range above
the Cuto
HPF: cuts the frequency range
below the Cuto
Cof Freq
(Cuto Freq)
200–8000 Hz
Center frequency when using the
lter to cut a specic frequency
range
Pre Delay 0.0–100.0 ms
Adjusts the delay time from the
direct sound until the anger sound
is heard.
Sync Hz, NOTE
Hz: The Rate value is specied in Hz.
NOTE: The Rate value is specied as
a note value.
Rate #
0.05–10.00 Hz,
note
Rate of modulation
Depth 0–127 Depth of modulation
Phase 0–180 deg Spatial spread of the sound
Feedback # -98–+98%
Adjusts the proportion of the anger
sound that is fed back into the
eect.
Negative (-) values invert the phase.
Low Gain -15–+15 dB Amount of low-range boost/cut
High Gain -15–+15 dB Amount of high-range boost/cut
Balance #
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the anger sound (W)
Level 0–127 Output volume
