7-1 Usable Media
Conditions for Usable Media
Media width
182 to 762 mm (7.2 to 30 inches)
A) Cuttable media thickness
0.08 to 0.22 mm (3.2 to 8.6 mil)
(depending on media composition)
B) Maximum media thickness (including backing paper)
Printing only: 1.0 mm (39 mil)
When performing cutting: 0.4 mm (15 mil)
C) Roll outer diameter
Maximum 180 mm (7.1 inches)
D) Paper tube (core) inner diameter
50.8 mm or 76.2 mm (2 inches or 3 inches)
Roll weight
20 kg (44 lb.)
Other conditions
Media such as the following cannot be used
Media whose end is attached to the paper tube (core)
Media which is severely warped or which has a strong tendency to reroll
Media that cannot withstand the tensioning of the media take-up or feed system
Media whose paper tube (core) is bent or crushed
Media that bends under its own weight when loaded
Media having an inward curl (i.e., media whose print surface is on the inner side of the roll)
Media on a sagging roll
Media that is rolled unevenly
Media that has an electrostatic charge
This machine cannot necessarily print every kind of media. When selecting media, be
sure to carry out testing in advance to make sure that satisfactory printing quality is
obtained.
