Correcting Misalignment of the Printing and Cutting Positions
Procedure
1.
Check the setting for the [AUTO ENV. MATCH] menu item.
Make sure the [AUTO ENV. MATCH] menu item is set to "ENABLE."
P. 102, "Executing Environment Matching Automatically"
2.
Execute the [ADJUST BI-DIR] menu item.
Load the media.
P. 35, "Loading Media," p. 98, "How to Load Sheet Media"
Perform bidirectional adjustment.
P. 107, "Correcting for Misalignment in Bidirectional Printing," p. 108, "Correcting for Misalignment in Bidi-
rectional Printing More Precisely"
3.
Print a test pattern and cut it.
Press .
Press
several times.
Press .
Press .
Press
.
The test pattern is printed at three locations: at the two edges
and in the center.
When adjustment is needed, go on to the steps below.
Printing
position
Cutting
position
Cutting position and printing
position are misaligned.
Cutting position and print-
ing position are aligned.
Printing
position
Cutting
position
To Next Page
