168
Chapter 7 Specications
Chapter
7
Specications
7-4 Locations of the Power Rating and Serial Number Labe
ls
Serial Number
This is required when you seek maintenance, servicing,
or support. Never peel o the label or let it get dir
ty
.
Power Rating
Use an
elec
trical outlet
that
meets the
requirements
for
voltage, fr
equency, and amperage g
iven here
.
169
