Attach the media anges to the roll media.
If the inner diameter of the roll-media core measures 3 inches, t the media anges onto the
core, then turn each knob clockwise all the way to keep the media anges from falling out.
Detach the rear cover.
Place the roll media on the shafts and position its left and right edges to match
the grit patterns.
20 mm or more
20 mm or more
Be sure to ensure
the media is within
this range.
Rear cover
2 inches
3 inches
Roll-media
Knob
Match to the inner diameter
of the roll-media core.
Turn until the knob
stops rotating.
Press in to t on
securely.
To Next Page
