Controller functions
RES-445 Page 37
22 Alloy/range This step in the Configuration menu is
available up to software revision 027 only.
Various heatsealing band alloys and temperature
ranges can be selected here.
The corresponding characteristic for the controller
parameters is calculated on the basis of this setting.
Please be very careful to select the heat-
sealing band material with the correct
alloy.
The temperature range setting permits the con-
troller to be matched to the required operating
range. This also determines the scale for the bar
display and the analog output.
(Availability depends on
software revision)
TCR 410ppm, 300°C
TCR 460ppm, 300°C
TCR 510ppm, 300°C
TCR 570ppm, 300°C
TCR 630ppm, 300°C
TCR 700ppm, 300°C
TCR 780ppm, 200°C
TCR 780ppm, 300°C
TCR 780ppm, 400°C
TCR 780ppm, 500°C
TCR 870ppm, 300°C
TCR 980ppm, 300°C
TCR 1100ppm, 200°C
TCR 1100ppm, 300°C
TCR 1100ppm, 400°C
TCR 1100ppm, 500°C
TCR 3500ppm, 200°C
TCR 3500ppm, 300°C
203 Alloy Various heatsealing band alloys can be selected
here.
The corresponding characteristic for the controller
parameters is calculated on the basis of this setting.
Please be very careful to select the heat-
sealing band material with the correct
alloy.
(Availability depends on
software revision)
TCR 780ppm
TCR 1100ppm
TCR 3500ppm
variable
204 Temperature
coefficient
If you selected "Variable" with step 203, you can
specify the temperature coefficient of the heatse-
aling band material here in 10ppm increments using
the "UP" and "DOWN" keys.
400…4000ppm
205 Temperature range Various temperature ranges can be selected here.
The temperature range setting permits the con-
troller to be matched to the required operating
range. This also determines the scale for the bar
displayand the analog output.
200°C
300°C
400°C
500°C
206
[23]
Maximum
temperature
This menu item specifies the maximum selectable
set point (step 101 [1]) and the maximum selectable
preheating temperature (step 102 [2]) within the
range defined by step 205 [22].
0 to max. temperature
range (step 205 [22])
No. Name Description Setting range
!
!
!
