Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
114
Specifications and Reference Data
Fully compensated mass flow block (option code H01)
Calculates fully compensated mass flow based on
differential pressure with external process pressure and
temperature measurements over the Fieldbus segment.
Configuration for the mass flow calculation is easily
accomplished using the Rosemount Engineering
Assistant.
ASP diagnostics suite for F
OUNDATION Fieldbus
(option Code D01)
The 3051SF ASP Diagnostics Suite for F
OUNDATION Fieldbus
provides Abnormal Situation Prevention indication and
enhanced EDDL graphic displays for easy visual analysis.
The integral Statistical Process Monitoring (SPM)
technology calculates the mean and standard deviation of
the process variable 22 times per second and makes them
available to the user. The 3051SF uses these values and
highly flexible configuration options for customization to
detect many user-defined or application specific
abnormal situations (e.g. detecting plugged impulse lines
and fluid composition change).
Wireless self-organizing networks
Output
WirelessHART, 2.4 GHz DSSS.
Local display
The optional five-digit LCD can display user-selectable
information such as primary variable in engineering units,
percent of range, sensor module temperature, and
electronics temperature. Display updates at up to once
per minute.
Update rate
WirelessHART, user selectable 8 sec. to 60 min.
Power module
Overpressure limits
Transmitters withstand the following limits without damage:
Coplanar sensor module (single variable)
Coplanar multi-variable sensor module
(3051SF_1, 2, 5, or 6)
Static pressure limits
Coplanar sensor module
Operates within specifications between static line
pressures of:
Arithmetic 20 milliseconds
Signal Characterizer 20 milliseconds
Integrator 20 milliseconds
Output Splitter 20 milliseconds
Control Selector 20 milliseconds
Block Execution time
Field replaceable, keyed connection eliminates the risk
of incorrect installation, Intrinsically Safe
Lithium-thionyl chloride Power Module with
polybutadine terephthalate (PBT) enclosure. Ten-year
life at one minute update rate.
(1)
1. Reference conditions are 70 °F (21 °C), and routing data for
three additional network devices.
Note: Continuous exposure to ambient temperature limits
of-40 °F or 185 °F (-40 °C or 85 °C) may reduce specified life by
less than 20 percent.
Range
DP
(1)
1. The overpressure limit of a DP Sensor with the P9 option is 4500
psig (310,26 bar). The overpressure limit of a DP Sensor with the
P0 option is 6092 psig (420,00 bar).
3051SF_3, 4, 7, or D
1 2000 psi (137,90 bar)
2 3626 psi (250,00 bar)
3 3626 psi (250,00 bar)
Static
pressure
Differential pressure
Range 1 Range 2 Range 3
Range 3
GP/AP
1600 psi
(110,32 bar)
1600 psi
(110,32 bar)
1600 psi
(110,32 bar)
Range 4
GP/AP
2000 psi
(137,90 bar)
3626 psi
(250,00 bar)
3626 psi
(250,00 bar)
Range
DP Sensor
(1)
1. The static pressure limit of a DP Sensor with the P9 option is 4500
psig (310,26 bar). The static pressure limit of a DP Sensor with
the P0 option is 6092 psig (420,00 bar).
3051SF_3, 4, 7, or D
1 0.5 psia to 2000 psig (0,03 to 137,90 bar)
2 0.5 psia to 3626 psig (0,03 to 250,00 bar)
3 0.5 psia to 3626 psig (0,03 to 250,00 bar)
