Specifications and Reference Data
A.15.3 Physical specifications
Temperature measurement
Primary element technology A
Integral RTD
100 Ohm platinum RTD
4-wire RTD (a = 0.00385)
Physical details
Body
316/316L SST
Manifold head/valves
316 SST
Annubar Primary Element for primary element
technology A
Roughened surface finish
Flange studs and nuts
Customer supplied
Available as a spare part
Transmitter connection studs and nuts
Studs– A193 Grade B8M
Nuts– A194 Grade 8M
Gasket and O-rings
Gaskets are customer supplied.
Gaskets and O-rings are available as spare parts.
Note
Gaskets and O-rings should be replaced when the 405 is
disassembled.
Transmitter connections
Direct mount
Available with 3051SMV, 3051S, 3051, 2051
Transmitters, ranges 1, 2, and 3.
Remote mount
Alignment rings
ANSI 150 - 600# alignment ring is included as standard when
ordering for up to 8-in. line size. For the 10-in. and 12-in. line
size, the alignment ring must be ordered (Installation
Accessories).
Remote Mount transmitter connections available with
1
/2-in. NPT for primary element technology A.
Table 29. Mounts Between the Following Flange
Configurations
ASME
B16.5
(ANSI)
DIN JIS
Class 150
Class 300
Class 600
PN16 (option code G)
PN40 (option code H)
PN100 (option code H)
10k (option code B)
20k (option code R)
40k (option code S)
Table 30. 405A Weight (Measurement in lb. [kg])
Line Size
Direct Mount
(D3)
Remote Mount
(R3)
2-in. (50 mm) 5.59 (2.53) 7.26 (3.29)
3-in. (80 mm) 7.41 (3.36) 9.08 (4.12)
4-in. (100 mm) 9.18 (4.16) 10.85 (4.92)
6-in. (150 mm) 13.10 (5.94) 14.76 (6.70)
8-in. (200 mm) 17.12 (7.77) 18.78 (8.52)
10-in. (250 mm)
(1)
1. Only available as a special, EXXXX.
21.26 (9.64) 22.93 (10.40)
12-in. (300 mm)
(1)
27.49 (12.47) 29.16 (13.23)
