Appendix A: Specifications and Reference Data
September 2015
173
Specifications and Reference Data
A.14 405 Compact primary element ordering information
Rosemount 405 Compact Primary Element utilizes an easy to install direct mount primary
element assembly.
 Available with Conditioning Orifice Plate Primary Element Technology or Compact
Annubar Primary Element Technology
 405P/C orifice primary elements are based on ASME/ISO corner tap design
 Available in
1
/2- to 12-in. (15 to 300 mm) line sizes
Table 26. Rosemount 405C Compact Primary Element Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
Model Product description
405 Compact Primary Element
Primary element technology
A Annubar averaging pitot tube ★
C Conditioning orifice plate ★
P Orifice plate ★
Material type
S316 SST ★
Line size
005
(1)
1
/2-in. (15 mm) ★
010
(1)
1-in. (25 mm) ★
015
(1)
1
1
/2-in. (40 mm) ★
020 2-in. (50 mm) ★
030 3-in. (80 mm) ★
040 4-in. (100 mm) ★
060 6-in. (150 mm) ★
080 8-in. (200 mm) ★
100
(2)(3)
10-in. (250 mm) ★
120
(2)(3)
12-in. (300 mm) ★
Temperature measurement
T
(4)
Integral RTD ★
N No temperature measurement ★
R Remote thermowell and RTD
Primary element type
000 Annubar sensor size 1 ★
